Our Products

Our advanced RFPAs and their associated subsystems help counter most known threats and exploit the most common opportunities in today’s challenging EW environment. And because our design engineers constantly research new developments in technology and hardware, our products are ready to respond to what tomorrow brings too.

RF Power Amplifiers

Known for their unrivalled performance and reliability, our RPFAs make the most of modern technology. For example, their significant processing power means they can link seamlessly into our customers’ systems to support operations in a CEMA environment.

Our RFPA capabilities include:

01

Modules, pallets and rack-mounted systems

02

Operation in CW or pulsed applications, in particular where efficient wide-band performance is necessary

03

Frequency from 20 MHz - 20 GHz

04

Powers up to several hundred watts

05

Use of Gallium Nitride (GaN) and Gallium Arsenide (GaAs) technologies

06

MMICs and LDMOS

07

Ultra-fast onboard switching

Examples of some COTS RFPAs

VHF / HF / UHF Amplifier MP1BC

MP1BN

20MHz to 520MHz 25W High efficiency GaN Power amplifier

Download
VHF / HF / UHF Amplifier MP1BC

MP1BC2

20MHz to 520MHz 25W High efficiency GaN Power amplifier

Download
L/S Band Amplifier Module MP2B

MP2B

400MHz-3GHz 20W High efficiency GaN power amplifier

Download
S/C Band RF Amplifier MP3C

MP3C

2.5GHz-6.0GHz 25W High efficiency GaN power amplifier

Download
C/X Band Amplifier MP45B

MP45B

5.7GHz-12.7GHz 20W Power Amplifier

Download
Vehicle Mount RF Power Amplifier VM1K

VM1K

20MHz-600MHz 150W High efficiency GaN power amplifier

Download
CEMA / ECM RF Power Amp Module - VM2F

VM2F

500MHz-2.7GHz 80w High efficiency GaN power amplifier

Download
L/S Band RF Power Amplifier VM2K

VM2K

500MHz-2.7GHz 100Wmin High-power density GaN power amplifier

Download
S Band Microwave Amplifier VM3F

VM3F

2.0GHz-6GHz 60W High-power GaN power amplifier

Download
VM900J 4G/2G Amplifier Module

VM900J

880MHz-1GHz 100W Power amplifier

Download
VM1800J - 2G/GSM L Band Power Amplifier

VM1800J

1750MHz-1900MHz 100W Power amplifier

Download
VM2100J - S Band RF power amplifier

VM2100J

2080MHz-2190MHz 100W Power amplifier

Download
blank

TX-RX Power Amplifier

12.5 WATT, 4.8GHz - 5GHz Solid-state LPA & LNA module

Download

Intelligent Range

Antares VM1T-iB solid state power amplifier module

VM1T-iB

200 WATT, 20-520 MHz Solid-state power amplifier module

Download
Intelligent RF Microwave Power Amplifier VM1J-iB

VM1J-iB

100-watt, 20MHz - 1GHz Intelligent Solid-state RFA

Download
C Band / L Band Intelligent PA VM2J-iB

VM2J-iB

100 WATT, 400-2900 MHz Solid-state power amplifier module

Download
Intelligent C Band Amplifier Module VM3E-iB

VM3E-iB

50-watt, 6GHz Intelligent Solid-state RFA

Download

Under Development

MP1B-i

15 WATT, 20MHz-520MHz Solid-state power amplifier module

Download

MP2B-i

15 WATT, 400MHz-2.7GHz Solid-state power amplifier module

Download

MP3B-i

15 WATT, 2GHz-6GHz Solid-state power amplifier module

Download
Products listed are a representative sample. For full details of all our products, please get in touch

High power switches

Our high-power, high-speed switches are robust enough to withstand the harsh conditions our customers operate in, such as extremely poor VSWR high temperatures.

Our switches use the test PIN diode and GaN technology, normally used for Transmit/Receive duplexing. Their multi-octave broadband designs typically cover the frequency range 20 MHz to 6 GHz at power levels exceeding 100 Watts.

VSWR monitors

We can design VSWR monitors into our products to meet your specific needs. These include broadband detection and high levels of isolation and power handling.

Receivers

We specialize in broadband, fast-scanning receivers with particular emphasis on low SWaP profile (size, weight and power). Our receivers operate from several kHz to 6 GHz and use proprietary techniques to ensure leading scan rates and a wide dynamic range.

Firmware and software

Our firmware and software expertise means we can equip our products with a contemporary digital interface that integrates seamlessly into your systems. This allows for unique, advanced features that include comprehensive Built-in-Test (BIT), Telemetry and Protection.
